Analog Inputs
- 2 pairs - stereo analog line level inputs (CD, Aux).
- 1 pair - stereo phono inputs (switchable; moving magnet or moving coil).
- Tuner - FM (with external antenna input; 15 station presets).
Digital Inputs
- 1 - digital coax (S/PDIF); 24/192k.
- 1 - digital optical (Toslink); 24/192k.
- 1 - digital USB (DAC input); 24/192k.
- 1 - Bluetooth receiver up to 44.1K (Bluetooth 5, with AptX, AptX HD, and AAC support, antenna included).
Outputs
- 1 pair - stereo full range main outputs.
- 1 pair - stereo high-pass outputs; with fixed 90 Hz Linkwitz-Riley high-pass filter.
- 1 - subwoofer output; with fixed 90 Hz Linkwitz-Riley low-pass filter.
- 1 - high performance stereo headphone output.
Analog Performance (line level)
- Maximum output level: 4 VRMS.
- Frequency response: 5 Hz to 50 kHz +/- 0.04 dB.
- THD+noise: < 0.001% (A-weighted).
- IMD: < 0.004% (SMPTE).
- S/N ratio: > 120 dB.
- Crosstalk: < 90 dB.
Analog Performance (speaker outputs)
• 60 watts RMS/channel; 8 Ohms; both channels driven; 20 Hz – 20 kHz; THD < 0.02%.
• 100 watts RMS/channel; 4 Ohms; both channels driven; at 1 kHz; THD < 1%.
• Minimum load impedance: 4 Ohms.
• Rated impedance: 8 Ohms.
• Frequency response:
20 Hz to 20 kHz +/- 0.15 dB
5 Hz to 80 kHz +0/-1.8 dB
• S/N ratio: > 116 dB
Analog Performance (phono)
• Frequency response (MM and MC): 20 Hz to 20 kHz; ref standard RIAA curve.
• THD+noise: < 0.015% (MM; A-weighted); < 0.06% (MC; A-weighted).
• S/N ratio: > 78 dB (ref 5 mV; MM); > 58 dB (ref 0.5 mV; MC).
• Gain (ref unity gain on main outputs at 1 kHz): 44 dB (MM); 55 dB (MC).
Analog Performance (headphone)
• Power Output:
8 Ohms: 23 mW / channel
33 Ohms: 90 mW / channel
47 Ohms: 127 mW / channel
150 Ohms: 145 mW / channel
300 Ohms: 114 mW / channel
600 Ohms: 75 mW / channel
Digital Performance
• Frequency response:
5 Hz to 20 kHz +/- 0.15 dB (44k sample rate).
5 Hz to 80 kHz +/- 0.25 dB (192k sample rate).
• THD+noise: < 0.003% (A-weighted; all sample rates)
• IMD: < 0.007% (SMPTE)
• S/N ratio: > 110 dB ref rated output.
Trigger
Power Requirements
- Universal SMPS which accepts anywhere between 100 VAC and 240 VAC.
Controls And Indicators
• Power: rocker switch; rear panel.
• Standby: one front panel push.
• Two front panel pushbuttons: Input Select; menu operation.
• One front panel knob: Volume; Tuning; menu operation.
• Display: high visibility blue alphanumeric VFD display (dimmable).
• Remote Control: compact full-function infrared remote control (AAA batteries required).
• LEDs: amber Standby LED; blue illuminated legends for Input buttons and Headphone output.
Mechanical
• Dimensions:
17” wide x 2-5/8” high x 12-1/2” deep (unboxed; without connectors)
21” long x 7” high x 17-1/2” deep (boxed)
• Weight:
15 lbs (unboxed)
20 lbs (boxed)
